RB058LAM150
초저 IR 150V 3A SOD-128 쇼트키 배리어 다이오드
RB058LAM150
초저 IR 150V 3A SOD-128 쇼트키 배리어 다이오드
RB058LAM150은 일반 정류용에 최적인 쇼트키 배리어 다이오드입니다.
Product Detail
사양 :
Configuration
Single
Package Code
SOD-128
Mounting Style
Surface mount
Number of terminal
2
VRM[V]
150
Reverse Voltage VR[V]
150
Average Rectified Forward Current IO[A]
3
IFSM[A]
80
Forward Voltage VF(Max.)[V]
0.84
IF @ Forward Voltage [A]
3
Reverse Current IR(Max.)[mA]
0.003
VR @ Reverse Current[V]
150
Tj[℃]
175
Storage Temperature (Min.)[°C]
-55
Storage Temperature (Max.)[°C]
175
Package Size [mm]
4.7x2.5 (t=1.05)
특징 :
- Small power mold type (PMDTM)
- High reliability
- Super Low IR
