RPR-0730 (신제품)
Photo reflector
RPR-0730 (신제품)
Photo reflector
RPR-0730 is an analog optical sensor with infrared VCSEL (IrVCSEL) and phototransistor. It detects the approach of a person or object by reflecting light emitted from the IrVCSEL onto the nearby object.
Product Detail
사양 :
Interface
Analog
Integrated Capabilities
PS
IF (Absolute Maxmum Rating) [mA]
5
VCEO (Absolute Maxmum Rating) [V]
30
Dark Current(Max)[µA]
0.1
Collector Current[mA]
0.69~1.79
Temperature Range[°C]
-30 to 85
Focus Length (Recommended Operating Distances)[mm]
1
Emitter WaveLength (Typ.)[nm]
940
Package Size [mm]
2.0x1.0 (t=0.55)
Package Type
SMD
특징 :
- Extremely small / Surface mounting (2.0×1.0×0.55mm)
- Analog output
- Detection distance (～10mm)
- High detection accuracy
(line width 0.1mm ※distance between reflective objectand sensor is 1mm） - Visible light cutoff
- Low light leakage inside the product using micro slit
- Built-in Zener DI
